ELKON Elkoblock-25 Plus Block Making Machine

Objavljeno: 9d

ELKON Elkoblock-25 Plus Block Making Machine ELKON Elkoblock-25 Plus Block Making Machine: slika 2

ELKON Elkoblock-25 Plus Block Making Machine ELKON Elkoblock-25 Plus Block Making Machine: slika 3

ELKON Elkoblock-25 Plus Block Making Machine ELKON Elkoblock-25 Plus Block Making Machine: slika 4

ELKON Elkoblock-25 Plus Block Making Machine ELKON Elkoblock-25 Plus Block Making Machine: slika 5

ELKON Elkoblock-25 Plus Block Making Machine ELKON Elkoblock-25 Plus Block Making Machine: slika 6

ELKON Elkoblock-25 Plus Block Making Machine ELKON Elkoblock-25 Plus Block Making Machine: slika 7

Objavljeno: 9d

Brend

ELKON

Lokacija

Turkey, Esentepe Mah. Gazeteciler Sitesi, Dergiler Sok. No:13 Sisli/Istanbul Turkey

+90 212 ... Prikaži

+90 212 288 96 33 +90 542 447 66 71

Više informacija

ELKOBLOCK-25 PLUS Concrete Block Machine

Capacity (10 hours production): ~600 m² concrete paver or 10.000 pcs 20x40x20 cm hollow block

- For production of blocks from 60 mm to 300 mm

- Forming area: 1035x860 mm

- Pallet size: 1200x950x180 mm

HYDRAULICS

- High performance reliable hydraulic system Brand: REXROTH (GERMANY)

- 40 l/min capacity oil cooler with fan

- Proportional valve controls for changing production speed depending on product

VIBRATION

- Tamper head vibration motors: 2,1 kW x 2 units Brand: OLI WAM

- Vibrating table vibration motors: 4 kW x 2 units Brand: ELKON

DESIGN

- Heavy duty design, robust machine structure and certified high grade steels used in production ensures highest durability and longest life time

- Four columns design for tamper head

- Special steel used in important places ensures optimum performance for many years.

- Exchangeable wear plates (DOMEX S700)

- 1500 liters concrete hopper for backing and 1250 liters concrete hopper for hard face concrete with hydraulic discharge control

- Electrical control manual level indicator on concrete hopper

- Fully comply with CE safety regulations

- Safety guards around all required points

CONTROL SYSTEM & POWER BOARD

- Fully automatic control from user friendly automation system with SIEMENS PLC and Touch Screen.

- All electrical components inside power board are SIEMENS-GERMANY brand.

Empty Pallet feeding hopper and conveyor (Pallet Lowering)

Pallet Conveyor for Wet Products

Pallet Elevator for pallets with legs

Automatic ELKON Cubic Robot (Servo-Drive)

Delivery Pallet Conveyor

utomation System for Handling Equipment
