Liming Mobile Crushing and Screening Specification Package

Objavljeno: 1g 11m

Liming Mobile Crushing and Screening Specification Package Liming Mobile Crushing and Screening Specification Package: slika 2

Liming Mobile Crushing and Screening Specification Package Liming Mobile Crushing and Screening Specification Package: slika 3

Liming Mobile Crushing and Screening Specification Package Liming Mobile Crushing and Screening Specification Package: slika 4

Liming Mobile Crushing and Screening Specification Package Liming Mobile Crushing and Screening Specification Package: slika 5

Električni

Objavljeno: 1g 11m

Brend

LIMING

Godina proizvodnje

2024

Nov

Stanje

novo

Težina

62000 kg

Neto težina

62000 kg

Dužina

13800 mm

Širina

3150 mm

Visina

4500 mm

Kapacitet

150-320 TPH m³

Boja

žuta, siva

Lokacija

China, Zhengzhou, provincia Henan, China

Motor/pogon

gorivo

elektro

menjač

automatski

Telo/nadgradnja

materijal tela

Hardox gvožđe

pumpa

Dodatno

garancija

sertifikati

CE, ISO, GOST

Više informacija

Please contact us to purchase a Mobile Crushing and Screening Specification Package or learn more informations.

Feeding Equipment: 3YZS2160 vibrating feeder

Crushing Equipment: PF1315 impact crusher

Stable, Flexible, Efficient, Functional

Mobile Impact Crusher can process medium hard stones, and final products can be used in road, bridge, construction and water conservancy, etc. industries. As one process of crushing work, mobile Impact Crusher can meet different requirements about capacity and output size by changing models.

Applications: Primary coarse & medium crusher in mining, quarry, mixing and batching plant, road and building construction, highway, railway and subway, and water conservancy.

Learn More About Mobile Crushing and Screening Specification Package

1. It adopts ship form steel structure and low vehicle chassis with light weight. The volume is controlled reasonably. Hidden style traction frame is easy to be packed up and put up. The transportation turning radius is very small.

2. Feeding guard is lifted by hydraulic pressure, easy to be loaded and unloaded, conveniently and reliably to be fixed.

3. Feeding guard adopts hierarchical type with two layers structure which provides prerequisites for widening.

4. The vehicle control cabinet is equipped with high-tech LCD touch screen and PLC control system. LCD touch screen with man-machine dialogue function makes it possess the functions of key start, misuse tips and protection, electrical control operations, fault and safe tips. It is convenient, efficient and secure.

5. Grizzly bars of the feeder is capable to separate out the small-sized material as the wastes. By adopting the automatic separatory hatch door, materials in the wastes hopper would flow either with the side-opening belt conveyor, or with the main materials.

6. Height of belt conveyor is adjustable. It also can be twisted and folded.

7. Landing legs adopt hydraulic lift mode which is of convenient operation and reliable performance.

8. With overall streamlined body design and metallic paint spraying, this plant is the perfect combination of mechanics and aesthetics.
